45+5uF 45/5 MFD ±6% 370/440VAC 50/60Hz CBB65B Dual-Channel Operating Circular Starting Capacitor - Suitable for HVAC Systems, Condenser Straight, or Heat Pump Air Conditioning
4.3 (88 items)
Limited Time SaleUntil the end
22
54
47
$13.14 cheaper than the new price!!
Free shipping for purchases over $99 ( Details )
Free cash-on-delivery fees for purchases over $99
Free cash-on-delivery fees for purchases over $99
See all stores
Please note that the sales price and tax displayed may differ between online and in-store. Also, the product may be out of stock in-store.
New $21.90
Product details
| Management number | 227227815 | Release Date | 2026/05/09 | List Price | $8.76 | Model Number | 227227815 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【Capacitor Model】 Exporing Fun 45+5uF ±6% 370V/440V CBB65B AC Capacitor
- 【Capacitor Dimensions】 Diameter (65mm/2.56 inches) Height (95mm/3.74 inches)
- 【Installation of AC capacitor】The three terminals on the top are labeled as follows: "Herm"/"H" represents the compressor motor, "Fan"/"F" represents the fan, and "C" represents the common line. The Fan terminal features a dual-blade design, making it easy to replace. You can directly replace the labeled terminal
- 【Temperature Range and Safety】 Operating Temperature: -40℃ to +70℃ / -104℉ to +158℉, Safety Level: 10,000 AFC
- 【Replacement parts are applicable to the following models】: 97F9895, Z97F995, 97F9895BZ3, 27L880, TRCD455, TRCFD455, PRCFD455, 27L889, 97F9851, 97F9851S, 12788, RC0114, Z97F9895, 97F9895, TT-CAP-45/5/440R, HC98KA046, TP-CAP-45/5/440R, CAP050450440RT, HC98JA046, HCKS450D050R440Z, 00662441180262
| ASIN | B0FQ2SYV83 |
|---|---|
| Brand Name | Exploring Fun |
| Item Shape | Round |
| Unit Count | 1.0 Count |
| Capacitance | 45 Farad |
| Part Number | D1 |
| Manufacturer | Exploring Fun |
| Material Type | Aluminum |
| Mounting Type | Snap-In Mount |
| Maximum Voltage | 450 Volts |
| Operating Voltage | 450 Volts (AC) |
| Included Components | Communication capacitor |
| Capacitance Tolerance | 6% |
| Item Dimensions W x H | 2.56"W x 3.74"H |
| Lower Temperature Rating | 40 Degrees Celsius |
| Upper Temperature Rating | 70 Degrees Celsius |
| Maximum Storage Temperature | 70 Degrees Celsius |
